    60mm Square 160V DC High Voltage Bldc Motor

    Ask Lasest Price
    Model Number : HC57BLY
    Brand Name : Hontru
    Certification : CE ISO RoHS
    Price : Negotiation
    Delivery Time : 5-10 working days
    Payment Terms : T/T, PayPal, Western Union
    Supply Ability : 10000pcs/month
    • Product Details
    • Company Profile

    60mm Square 160V DC High Voltage Bldc Motor

    60mm Square Brushless Motor


    Specification


    Itemindex parameter
    Winding methodY
    Hall distribution angle120°
    Insulation levelB
    Insulation resistance100MΩ Min.500VDC
    Dielectric strength600VAC,1Min.
    Maximum radial load75N
    Maximum axial load15N

    Wiring
    Function DefinitionColorWire Gauge
    +5VRed

    AWG26 UL1430

    HuWhite
    HvBlue
    HwGreen
    GNDBlack
    UWhite

    AWG22 UL1430

    VBlue
    WGreen

    Motor modelHC60BLF78HC60BLF100HC60BLF120HC60BLF140
    Number of poles3
    Number of phases8
    Rated voltage (VDC)24
    Rated speed (rpm)3000
    Rated torque (N.m)0.250.50.751
    Rated current (A)4.38.71322
    Rated power (W)78157235315
    Peak torque (N.m)0.751.52.253.91
    Peak current (A)12.9263966
    Back EMF constant (Vrms/Krpm)6666
    Torque constant (N.m/A)0.0570.0570.0570.057
    Moment of inertia (g.cm2)150200250300
    Body length L (mm)78100120140
    Weight (kg)0.851.251.72.2

    Outline:

    60mm Square 160V DC High Voltage Bldc Motor
